OLT de 8 Puertos GPON TP-Link DS-P7001-08, Hasta 1024 Onus, 1 Gigabit RJ45, 2 Puertos SFP+, Fuentes Redundantes AC- DC (Incluidas)

Name: OLT de 8 Puertos GPON TP-Link DS-P7001-08, Hasta 1024 Onus, 1...
SKU: DS-P7001-08
Availability: InStock

Categoría: Redes SKU: DS-P7001-08

$26,788.00 IVA Incluido

Valorado en 0 de 5

💳 Paga hasta en 24 cuotas fijas con tu tarjeta de crédito

⚡ Precio exclusivo en línea Oferta válida comprando en pcdigital.com.mx

63 In Stock.

Descripción

HARDWARE FEATURES
Interface	• 8× 2.5G PON Ports • 2× 10 Gbps SFP+ Uplink Ports • 1× 10/100/1000 Mbps RJ45 Uplink Port • 1× RJ45 Console Port • 1× RJ45 MGMT Port • 1× Alarm Port (Reserved)
Button	Reset Button
Power Supply	• Dual Power Supplies: 2 AC, 2 DC or AC+DC, • AC: 100V~240V, 50/60Hz • DC: -38.4V~-72V
Power Consumption	Max. 70W
Dimensions ( W x D x H )	17.3 × 10.2 × 1.7 in (440 × 260 × 44 mm)

SOFTWARE FEATURES
Security	• ACL • 802.1x Authentication • ARP Inspection • IP Source Guard
DHCP	• DHCP Server • DHCP Relay
OMCI	Standard OMCI Management Supported
ONU Authentication	ONU Auto Authentication
ONU Security	• Rouge ONU Detection and Isolation • Uplink and Downlink Data Encryption
Multi-Service	Multi-Service Traffic Identify and Rate Limit
QoS	• IEEE 802.1p/DSCP QoS • Voice VLAN • Auto VoIP
Routing	Static Routing
Mulitcast	• IGMP Snooping • MLD Snooping
Centralized Management	• Large-Scale Devices Management • OLT Batch Configure, Upgrade, Reboot • Multi-Site Management • Intelligent Network Monitoring • Real-time Network Overview

OTHERS
Certification	CE,FCC
Package Contents	• OLT Device • Power Cord and Console Cable • Installation Guide • Mouting Brackets, Screws and Rubber Feet
Environment	• Operating Temperature: 0°C~50°C (32°F~122°F) • Storage Temperature: -40℃~70℃(-40°F ~158°F)

GPON PORT ATTRIBUTE
Max. Splitting Ratio	1:128
Transmission distance	20 km
Data rate	• Downstream: 2.5 Gbps • Upstream: 1.25 Gbps
Wavelength	• Tx: 1490 nm • Rx: 1310 nm
Interface type	SC/UPC
Fiber type	9/125μm SMF (Single Mode Fiber)
Tx power	Class C+

Peso	5 kg
Dimensiones	44 × 53 × 10 cm
