Fabricante: TP-Link
Código de Producto: CPE605
Tiempo de Entrega: 48 Horas
Peso: 3.50 Kg.
Garantia: 2 AÑOS (01 800)
  ¡Verifica Existencias en nuestras sucursales!
  Solicita Cotización por Volumen

  ¡Solicita un mejor precio!
$718.50$799.00
Ahorras: $80.50(10%)

Formas de Pago:

  Tarjeta de crédito o débito
    Tienda de conveniencia
  Depósito o transferencia bancaria
CARACTERÍSTICAS DE HARDWARE
ProcesadorQualcomm 560MHz CPU, MIPS 74Kc
Memoria64MB DDR2 RAM,8MB Flash
Interface1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button
Fuente de AlimentaciónPassive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC
Dimensiones (W X D X H)350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Ganancia de Antena23dBi
Cobertura de Antena7°(Azimuth), 10°(Elevation)
Protección15KV ESD Protection
6KV Lightning Protection
CercadoMaterial: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design
CARACTERÍSTICAS INALÁMBRICAS
Estándares InalámbricosIEEE 802.11a/n
Protocolo PropietarioTDMA Mode (with Pharos MAXtream enabled)
Velocidades InalámbricasUp to 150Mbps (40MHz,Dynamic)
Up to 72.2Mbps (20MHz,Dynamic)
Up to 36.1Mbps (10MHz,Dynamic)
Up to 18.05Mbps (5MHz,Dynamic)
Frecuencia5.15~5.85GHz
Potencia de TransmisionMax. 23dBm (Adjustable power by 1dBm)
CARACTERÍSTICAS DE SOFTWARE
Network ConfigurationWAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding
Wireless ConfigurationsPharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
ManagementDiscovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
System ToolsIndicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
System-level OptimizationsOptimized IGMP Snooping/Proxy for multicast applications
Hardware watch dog
POE ADAPTER FEATURES
Dimensions(W x D x H)85.8×43.9×29.7 mm
Interfaces1 AC Jack with Earth Ground
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)
ButtonRemote Reset Button
Power Status LEDsGreen
Input100-240VAC, 50/60Hz
Output24VDC, 0.6A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficiency>84.29%
CertificationsCE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
OTHERS
CertificationCE, FCC, RoHS, IP65
Package ContentsOutdoor Wireless CPE
24V 0.5A Passive PoE Adapter
Pole Mounting Straps
AC Power Cord
Installation Guide
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
EnvironmentOperating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
